Revolutionizing In-Vehicle Embedded Computing: AAEON’s BOXER-8658AI with 8 PoE LAN Ports
The AAEON BOXER-8658AI is a powerful computing system designed for use in vehicles. It features eight PoE LAN ports, E-Mark certification, and a high level of serial communication capabilities, setting a new standard for in-vehicle embedded computing.
AAEON has introduced a new embedded AI system, the BOXER-8658AI, which is part of their lineup of products based on the NVIDIA Jetson Orin NX. Specifically designed for use in vehicles, the BOXER-8658AI features eight PoE LAN ports (802.3af/at), GNSS, a 9-axis sensor, E-Mark certification, and 9V to 36V input with accessory ignition delay on/off.
Important specifications
The BOXER-8658AI is built to be easily set up and withstand tough conditions, meeting MIL-STD-810G standards for shock and vibration resistance. It can operate in temperatures ranging from -15°C to 60°C and has dimensions of 8.27’’ x 6.46’’ x 2.99’’ (9.69’’ x 6.46’’ x 3.27’’ with brackets). It can be conveniently mounted on a wall and does not need an extra power supply for mobile use due to its PoE port selection.
The BOXER-8658AI allows for communication with different vehicle systems, sensors, and equipment through its I/O features. It includes four USB 3.2 Gen 2 ports, as well as DB-9 and DB-15 ports for CANBus and RS-232/422/485. The DB-15 port also supports 8-bit DIO, and optional UART/I2C connector enables GPS and 9-axis sensor board support.
The BOXER-8658AI offers various ways to connect wired peripherals, as well as seven antenna openings for Wi-Fi and LTE communication. These can be accessed through the PC's M.2 2230 E-Key and M.2 3052 B-Key slots. Expansion options also include an M.2 2280 M-Key for NVMe, a SATA drive bay, and two SIM card slots.
AAEON acknowledges that the BOXER-8658AI is suitable for use in vehicles or for Industrial Network Video Recorder (NVR) applications. It can utilize the NVIDIA Jetson Orin NX's 100 TOPS of performance and 1024-core NVIDIA Ampere architecture GPU to perform complex AI inference tasks with the large amounts of data collected from connected peripherals.
You can now pre-order the BOXER-8658AI on the eShop, which comes in different versions with either 8GB or 16GB NVIDIA Jetson Orin NX modules. It also includes LPDDR5 system memory with matching capacity.
To learn more and see specific details, please go to the product page for the BOXER-8658AI.
